MB96340 Series

Document Number: 002-04579 Rev. *A

Page 12 of 109

RDY

External bus

External bus interface external wait state request input

RSTX

Core

Reset input

RXn

CAN

CAN interface n RX input

SCKn

USART

USART n serial clock input/output

SCKn_R

USART

Relocated USART n serial clock input/output

SCLn

I2C

I2C interface n clock I/O input/output

SDAn

I2C

I2C interface n serial data I/O input/output

SINn

USART

USART n serial data input

SINn_R

USART

Relocated USART n serial data input

SOTn

USART

USART n serial data output

SOTn_R

USART

Relocated USART n serial data output

TINn

Reload Timer

Reload Timer n event input

TOTn

Reload Timer

Reload Timer n output

TTGn

PPG

Programmable Pulse Generator n trigger input

TXn

CAN

CAN interface n TX output

UBX

External bus

External Bus Interface Upper Byte select strobe output

VCC

Supply

Power supply

VSS

Supply

Power supply

WOT

RTC

Real Timer clock output

WRHX

External bus

External bus High byte write strobe output

WRLX/WRX

External bus

External bus Low byte / Word write strobe output

Clock

Oscillator input

X0A

Clock

Subclock Oscillator input (only for devices with suffix "W")

Clock

Oscillator output

X1A

Clock

Subclock Oscillator output (only for devices with suffix "W")

Table 1: Pin Function description

Pin name

Feature

Description
