MB96340 Series

Document Number: 002-04579 Rev. *A

Page 101 of 109

16. Package Dimension MB96(F)34x LQFP 100P

100-pin plastic LQFP

Lead pitch

0.50 mm

Package width

package length

14.0 mm

× 14.0 mm

Lead shape

Gullwing

Sealing method

Plastic mold

Mounting height

1.70 mm Max

Weight

0.65 g

Code

(Reference)

P-LFQFP100-14

×14-0.50

100-pin plastic LQFP

(FPT-100P-M20)

2005 -2008 FUJITSU MICROELECTRONICS LIMITED F100031S-c-3-3

14.00±0.10(.551±.004)SQ

16.00±0.20(.630±.008)SQ

100

0.50(.020)

0.20±

0.05

(.008±.002)

0.08(.003)

0.145±0.055

(.0057±.0022)

0.08(.003)

"A"

INDEX

.059 –.004

+.008

–0.10

+0.20

1.50

(Mounting height)

0°~8°

0.50±0.20

(.020±.008)

(.024±.006)

0.60±0.15

0.25(.010)

0.10±0.10

(.004±.004)

Details of "A" part

(Stand off)

Dimensions in mm (inches).

Note: The values in parentheses are reference values

Note 1) * : These dimensions do not include resin protrusion.

Note 2) Pins width and pins thickness include plating thickness.

Note 3) Pins width do not include tie bar cutting remainder.
