ADL5569BCPZ-R7 데이터시트(PDF) 4 Page - Analog Devices

부품명 ADL5569BCPZ-R7
상세설명  6.5 GHz, Ultrahigh Dynamic Range, Differential Amplifier
PDF  23 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  AD [Analog Devices]
홈페이지  http://www.analog.com
Logo AD - Analog Devices

ADL5569BCPZ-R7 데이터시트(HTML) 4 Page - Analog Devices

  ADL5569BCPZ-R7 Datasheet HTML 1Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 2Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 3Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 4Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 5Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 6Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 7Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 8Page - Analog Devices ADL5569BCPZ-R7 Datasheet HTML 9Page - Analog Devices Next Button
Zoom Inzoom in Zoom Outzoom out
 4 / 23 page
background image
ADL5569
Data Sheet
Rev. C | Page 4 of 23
Parameter
Test Conditions/Comments
Min
Typ
Max
Unit
NOISE/HARMONIC PERFORMANCE
100 MHz
Second Harmonic Distortion (HD2)
−89
dBc
Third Harmonic Distortion (HD3)
−83
dBc
Output Third-Order Intercept (OIP3)
42
dBm
Third-Order Intermodulation Distortion (IMD3)
−82
dBc
Output Second-Order Intercept (OIP2)
74
dBm
Second-Order Intermodulation Distortion (IMD2)
−73
dBc
Output 1 dB Compression Point (OP1dB)
17.4
dBm
Noise Figure2
5.4
dB
Noise Spectral Density (NSD), RTI2
1.0
nV/√Hz
500 MHz
HD2
−78
dBc
HD3
−71
dBc
OIP3
41
dBm
IMD3
−80
dBc
OIP2
74
dBm
IMD2
−73
dBc
OP1dB
17.2
dBm
NF2
6.3
dB
NSD, RTI2
1.2
nV/√Hz
1000 MHz
HD2
−65
dBc
HD3
−58
dBc
OIP3
39
dBm
IMD3
−76
dBc
OIP2
71
dBm
IMD2
−70
dBc
OP1dB
17.7
dBm
NF2
7.0
dB
NSD, RTI2
1.3
nV/√Hz
2000 MHz
HD2
−64
dBc
HD3
−52
dBc
OIP3
34
dBm
IMD3
−65
dBc
OIP2
63
dBm
IMD2
−62
dBc
OP1dB
17.4
dBm
NF2
9.3
dB
NSD, RTI2
1.8
nV/√Hz
3000 MHz
HD2
−62
dBc
HD3
−46
dBc
OIP3
30
dBm
IMD3
−58
dBc
OIP2
57
dBm
IMD2
−56
dBc
OP1dB
16.2
dBm
NF2
11.1
dB
NSD, RTI2
2.2
nV/√Hz
