ADL5569

Data Sheet

Rev. C | Page 6 of 23

ABSOLUTE MAXIMUM RATINGS

Table 2.

Parameter

Rating

Output Voltage Swing × Bandwidth Product

5 V-GHz

Supply Voltage (VS) at VCC and VCC2

5.25 V

VIP, VIP2, VIN, and VIN2

VS + 0.5 V

PDB, PDB2

3.6 V

Maximum Output Current, IOUT (VIP, VIP2,

VIN, and VIN2 Pins)

±30 mA

Internal Power Dissipation

1 W

Maximum Junction Temperature

125°C

Operating Temperature Range

−40°C to +85°C

Storage Temperature Range

−65°C to +150°C

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

THERMAL RESISTANCE

Thermal performance is directly linked to PCB design and

operating environment. Careful attention to PCB thermal

design is required.

θJA is the natural convection junction to ambient thermal

resistance measured in a one cubic foot sealed enclosure. θJC

is the junction to case thermal resistance.

Table 3. Thermal Resistance

Package Type

θJA1

θJC2

Unit

CP-16-44

90.5

20.9

°C/W

Measured on an Analog Devices evaluation board.

Based on simulation with JEDEC standard JESD51.
