10. I2C Function

The P9222-R/RN uses the standard I2C slave implementation protocol to communicate with a host AP or other I2C peripherals. The

communication protocol is implemented by using 8 bits for data and 16 bits for addresses. The default slave address of the P9222-R/RN is

0x61h.

When writing to the P9222-R/RN, care should be taken to only write to registers marked exclusively as Read/Write (RW). Registers marked as

Read Only (R) should never be sent a Write command or unexpected behavior may occur. In addition, register locations marked Reserved

should not receive a Write command. When writing to a RW register that contains a combination of RW fields and reserved fields, a read-

modify-write should be performed to the intended bit/field only. All other bits/field, including reserved bits/fields, should NOT be modified.

The P9222-R/RN Rx device operates in Rx mode. Depending on the firmware (FW) loaded into OTP memory or updated by the AP, the P9222-

R/RN Rx will follow the programmed settings once connected wirelessly to a Tx. Some registers are defined and implemented for Read-only,

some registers are Read/Write, and some registers are volatile and will be reset if power is cycled.

11. Registers

The P9222-R/RN uses the standard I2C slave implementation protocol to communicate with a host AP or other I2C peripherals. The

communication protocol is implemented using 8 bits for data and 16 bits for addresses. The default slave address of the P9222-R/RN is 0x61.

The following tables list address locations, field names, available operations (R or RW), default values, and functional descriptions of internally

accessible registers contained within the P9222-R/RN. The OTP registers are loaded each time the device is powered and cannot be changed

except by new firmware programmed into a blank device. The SRAM registers are available to make setting changes after the device is powered.

These changes are reset to default when the power is cycled or the device is reset.

Table 11. Chip Part Number ID Register, Chip_ID_L (0x00), Chip_ID_H (0x01)

Address

and Bit

Register Field Name

R/W

Default

Value

Function and Description

0x00 [7:0]

Chip_ID_L

R

0x22

Chip ID low byte

0x01 [7:0]

Chip_ID_H

R

0x92

Chip ID high byte

Table 12. Chip Revision Register, Chip_Rev (0x02)

Address

and Bit

Register Field Name

R/W

Default

Value

Function and Description

0x02 [7:0]

Chip_Rev

R

0x02

Chip main revision. Latest chip revision is 0x02 (default).
