13. Package Outline Drawings

The package outline drawings are located at the end of this document and are accessible from the Renesas website (see package links in

Ordering Information). The package information is the most current data available and is subject to change without revision of this document.

14. Marking Diagram

IDT

P9222

YYWW**

$-R

NNCCRR

•

Line 1 is the manufacturer (Renesas).

•

Line 2 is the truncated part number.

•

Line 3: “YYWW” is the last digit of the year and week that the part was assembled.

“**” denotes sequential lot number.

•

Line 4: “$” denotes mark code; “R” is part of the device part number for P9222-R.

•

Line 5: "NN” is the wafer number; “CC” is the column or X- coordinate of the wafer;

“RR” is the row or Y-coordinate of the wafer

IDT

P9222

YYWW**

$-RN

NNCCRR

•

Line 1 is the manufacturer (Renesas).

•

Line 2 is the truncated part number.

•

Line 3: “YYWW” is the last digit of the year and week that the part was assembled.

“**” denotes sequential lot number.

•

Line 4: “$” denotes mark code; “R” is part of the device part number for P9222-RN.

•

Line 5: "NN” is the wafer number; “CC” is the column or X- coordinate of the wafer;

“RR” is the row or Y-coordinate of the wafer

15. Ordering Information

Part Number[a]

Description

Package

MSL Rating

Carrier Type

Temperature Range

P9222-RAZGI8

Firmware factory programmed in

internal OTP is WPC 1.2.4 Qi BPP

compatible

40-WLCSP, 2.28 × 3.38

mm, 0.4mm pitch

MSL-1

Reel

-40°C to +85°C

P9222-RNAZGI8

Firmware factory programmed in

internal OTP is WPC 1.3 Qi BPP

compatible

40-WLCSP, 2.28 × 3.38

mm, 0.4mm pitch

MSL-1

Reel

-40°C to +85°C

[a] In the part ordering number, the code after the dash indicates specific customer firmware requirements. A dash code of -0 indicates devices

that have not been programmed.
