9 / 72 page  DocID026217 Rev 1 9/72 STLED524 Application schematic Note: All above components refer to a typical application. The device operation is not limited to the choice of these external components. Figure 2. Pin configuration (top view) Table 2. Typical external components Component Manufacturer Part number Value Size C1 Murata GRM188R60J106ME84D 10 µF 0603 C2 Murata GRM188R60J106ME84D 10 µF 0603 C3 Murata GRM188R60J106ME84D 10 µF 0603 C4 Murata GRM21AR60J226ME47L 22 µF 0805 C5 Murata GRM21AR60J226ME47L 22 µF 0805 L Murata LQM2HPN1R0MJC 1.0 µH 2.0x1.6x0.9 mm RSET 25 k 0402 R1 15 k 0402 1 2 3 4 5 6 7 A GND VDD RESET VSUP VBAT1 PGND PGND B CLKOUT CLKIN SCK ISET LDOGND SW SW C MISO MOSI INT TEST VBAT2 VOUT VOUT D VIO SYNC SS COL23 COL0 AGND1 ROW0 E COL21 COL20 COL19 COL22 COL8 COL1 ROW1 F COL18 COL17 COL15 COL9 COL3 COL2 ROW2 G COL16 COL13 COL11 AGND2 COL6 COL4 ROW3 H COL14 COL12 COL10 AGND2 COL7 COL5 ROW4 MISO GIPG2702141312LM |
|
