20. Main Changes in this Edition

NOTE: Please see “Document History” for later revised information.

Document History

Spansion Publication Number: DS07-13802-3E

Page

Section

Change Results

Electrical Characteristics

14.5. Analog Digital Converter

Corrected "Value" and "Unit" of Zero reading voltage.

(AVRL - 1.5

 AVRL - 1.5 LSB

AVRL + 0.5

 AVRL + 0.5 LSB

AVRL + 2.5

 AVRL + 2.5 LSB

LSB

 V)

Corrected "Value" and "Unit" of Full scale reading voltage.

(AVRH - 3.5

 AVRH - 3.5 LSB

AVRH - 1.5

 AVRH - 1.5 LSB

AVRH + 0.5

 AVRH + 0.5 LSB

LSB

 V)

Document Title: MB96345/346, MB96F345, MB96F346/F347/F348, F2MC-16FX, MB96340 Series, 16-bit Proprietary

Microcontroller Datasheet

Document Number: 002-04579

Revision

ECN

Orig. of

Change

Submission

Date

Description of Change



AKIH

06/17/2009

Migrated to Cypress and assigned document number 002-04579.

No change to document contents or format.

5198948

AKIH

04/04/2016

Updated to Cypress template
