Product Specification (V1.1) 09.13.2005

•••• v

Specification Revision History

Doc. Version

Revision Description

Date

0.1

Preliminary version

2005/05/05

0.2

1. Modified the interface type selection table (table2)

2. Modified the parallel interface table (table3)

3. Pins renamed: VDD2 VCI, RW R/WB, C86 M86,

P_S P/S, CLS CKS, CL CK, FR M, FRS FLM

4. Added Pin coordinate table in Pin configuration on

page 4 ~ 7

2005/05/10

0.3

1. Modified the Pin Coordinate Table (pin 71 ~ pin 78 X

coordinate) on page 4

2. Added Alignment Key (A1, A2) to Pin Configuration

table on page 3

3. Deleted Part No. EM62100AU, EM62100BU from the

Package table on page 3

4. Modified VDD, VDD2, VSS, VSS2,VSS3 function in

Pin Description on page 7

5. Pins renamed: D0 to D7 D0, D1, D2, D3, D4, D5, D6

(SCL), D7 (SI), R/WB RW, on page 8, VCI

VEE

and modified the VEE pin function description on page

6. Deleted 6.12.4 voltage follower down control

7. Modified 6.13.1 item mark and Added 6.13 description

on page 25

8. Added section 7. Command Register & Decoder

description on page 26

9. Modified the Command Function Table E RDB

RDB , R/W WRB WRB

10. Modified section 7.2.5 Read status table: RDB=1,

WRB=0

RDB=0 , WRB=1 on page 31

11. Modified section 7.2.16 Power Control Set table: A2,

A1, A0

VB, VR, VF on page 35

12. Modified section 9 DC Characteristics: Hz

Hi-z on

page 38 , VOUT`1 ~VOUT4 MAX RATING

5XVDD2X0.99 ~ 2XVDD2X0.99

5XVDD2 ~

2XVDD2

13. Added No. of pins in Pin Description table on pages

7 ~ 10

14. Added Pin Configuration on page 2

15. Added sections 3.1 Pin Dimensions , 3.2 Mark

Dimensions, 3.3 Alignment Key on page 3

16. Modified Pin Description: swapped Pin names CAP1

; CAP2

2005/06/15

1.0

1. Added Timing rating to AC Characteristics table on

page 49~52.

2. Added be take notice of item in serial mode on page 51

3. Added fFRM rating and Base Voltage rating to AC

Characteristics table on page 47~48.

4. Modified VREF pin input only and the function in Pin

Description on page 7

5. Added Current consumption to DC Characteristics

table on page 47

2005/8/16
