background image
EM62100
65 COM/132 SEG STN LCD Driver
2 •
•••
Product Specification (V1.1) 09.13.2005
(This specification is subject to change without further notice)
1
62
63
78
79
122
123
139
140
295
296
312
Right Mark
Left Mark
Internal RC oscillator circuit (external clock can also be input)
Extremely low power consumption
Power supply, operable on the low 1.8 voltage,
Logic power supply VDD – VSS = 1.8 to 3.6V,
Boost reference voltage: VEE= 1.8 to 3.6V,
LCD driver power supply: VLCD=V0 – VSS =4.0 to 14.2 V
These chips are not designed with resistance to light or resistance to radiation.
Package (Ordering information)
Part No.
Package Type
EM62100AGH
Gold Bump
3 Pin Configuration
