background image
EM351 / EM357
2-10
120-035X-000D
Preliminary
2.7.3
Synthesizer
Table 2-9 lists the key parameters of the integrated synthesizer on the EM35x.
Table 2-9. Synthesizer Characteristics
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
Frequency range
2400
2500
MHz
Frequency resolution
11.7
kHz
Lock time
From off
100
μs
Relock time
Channel change or Rx/Tx turnaround (IEEE
802.15.4-2003 defines 192 μs turnaround
time)
100
μs
Phase noise at 100 kHz offset
-75
dBc/Hz
Phase noise at 1 MHz offset
-100
dBc/Hz
Phase noise at 4 MHz offset
-108
dBc/Hz
Phase noise at 10 MHz offset
-114
dBc/Hz
