background image
EM351 / EM357
The GPIO pins that can be assigned to these signals are shown in Table 8-5.
Table 8-5. SPI Slave GPIO Usage
MOSI
MISO
SCLK
nSSEL
Direction
Input
Output
Input
Input
GPIO Configuration
Input
Alternate Output
(push-pull)
Input
Input
SC1 pin
PB2
PB1
PB3
PB4
SC2 pin
PA0
PA1
PA2
PA3
8.4.2
Set Up and Configuration
Both serial controllers, SC1 and SC2, support SPI slave mode. SPI slave mode is enabled by the following
register settings:
The serial controller mode register, SCx_MODE, is 2
The SC_SPIMST bit in the SPI configuration register, SCx_SPICFG, is 0
The SPI slave controller receives its clock from an external SPI master device and supports rates up to 5 Mbps.
8-15
120-035X-000D
Preliminary
