background image
EM351 / EM357
GPIO_DBGCFG
GPIO Debug Configuration Register
Address: 0x4000BC00 Reset: 0x10
31
30
29
28
27
26
25
24
0
0
0
0
0
0
0
0
23
22
21
20
19
18
17
16
0
0
0
0
0
0
0
0
15
14
13
12
11
10
9
8
0
0
0
0
0
0
0
0
7
6
5
4
3
2
1
0
0
0
GPIO_DEBUGDIS
GPIO_EXTREGEN
GPIO_DBGCFGRSVD
0
0
0
Bitname
Bitfield
Access
Description
GPIO_DEBUGDIS
[5]
RW
Disable debug interface override of normal GPIO configuration.
0: Permit debug interface to be active.
1: Disable debug interface (if it is not already active).
GPIO_EXTREGEN
[4]
RW
Enable REG_EN override of PA7's normal GPIO configuration.
0: Disable override.
1: Enable override.
GPIO_DBGCFGRSVD
[3]
RW
Reserved: this bit can change during normal operation. When writing to GPIO_DBGCFG,
the value of this bit must be preserved.
7-21
120-035X-000D
Preliminary
