EM351 / EM357
8-24
120-035X-000D
Preliminary
SCx_TWICTRL2
SC1_TWICTRL2
TWI Control Register 2
Address: 0x4000C850 Reset: 0x0
SC2_TWICTRL2
TWI Control Register 2
Address: 0x4000C050 Reset: 0x0
31
30
29
28
27
26
25
24
0
0
0
0
0
0
0
0
23
22
21
20
19
18
17
16
0
0
0
0
0
0
0
0
15
14
13
12
11
10
9
8
0
0
0
0
0
0
0
0
7
6
5
4
3
2
1
0
0
0
0
0
0
0
0
SC_TWIACK
Bitname
Bitfield
Access
Description
SC_TWIACK
[0]
RW
Setting this bit signals ACK after a received byte. Clearing this bit signals NACK after a
received byte.
8.6
UART - Universal Asynchronous Receiver / Transmitter
The SC1 UART is enabled by writing 1 to SC1_MODE. The SC2 serial controller does not include UART functions.
The UART supports the following features:
Flexible baud rate clock (300 bps to 921.6 kbps)
Data bits (7 or 8)
Parity bits (none, odd, or even)
Stop bits (1 or 2)
False start bit and noise filtering
Receive and transmit FIFOs
Optional RTS/CTS flow control
Receive and transmit DMA channels
8.6.1
GPIO Usage
The UART uses two signals to transmit and receive serial data:
TXD (Transmitted Data) – serial data sent by the EM35x
RXD (Received Data) – serial data received by the EM35x
If RTS/CTS flow control is enabled, these two signals are also used:
nRTS (Request To Send) – indicates the EM35x is able to receive data
nCTS (Clear To Send) – inhibits sending data from the EM35x if not asserted
