EM351 / EM357
8-14
120-035X-000D
Preliminary
SCx_RATEEXP
SC1_RATEEXP
Serial Clock Exponential Prescaler Register
Address: 0x4000C864 Reset: 0x0
SC2_RATEEXP
Serial Clock Exponential Prescaler Register
Address: 0x4000C064 Reset: 0x0
31
30
29
28
27
26
25
24
0
0
0
0
0
0
0
0
23
22
21
20
19
18
17
16
0
0
0
0
0
0
0
0
15
14
13
12
11
10
9
8
0
0
0
0
0
0
0
0
7
6
5
4
3
2
1
0
0
0
0
0
SC_RATEEXP
Bitname
Bitfield
Access
Description
SC_RATEEXP
[3:0]
RW
The exponential component (EXP) of the clock rate in the equation:
rate = 12MHz / ( (LIN + 1) * (2^EXP) )
8.4
SPI - Slave Mode
Both SC1 and SC2 SPI controllers include a SPI slave controller with these features:
Full duplex operation
Up to 5 Mbps data transfer rate
Programmable clock polarity and clock phase
Selectable data shift direction (either LSB or MSB first)
Slave select input
8.4.1
GPIO Usage
The SPI slave controller uses four signals:
MOSI (Master Out, Slave In) – inputs serial data from the master
MISO (Master In, Slave Out) – outputs serial data to the master
SCLK (Serial Clock) – clocks data transfers on MOSI and MISO
nSSEL (Slave Select) – enables serial communication with the slave
