| 11

Simple ON/OFF detection

Reduced wiring and fast response

Easy version for

cost-efficiency

Fastest response time of

5 ms

The Easy type that allows the distance between the

light curtain and hazard source to be reduced is ideal

for the use in a small machine.

Easier to build safety

circuits

Only four wires are required for the minimum

configuration, which is as simple as wiring a

photoelectric sensor. Simple connection with a safety

controller makes it easy to build a safety circuit.

F3SG-

Use easy-to-obtain cables

Commercially available M12 connector cables can be used

as extension cables to build a safety circuit.

Emitter

G9SE

Power supply

Receiver

Industry's fastest class*

Simple safety functions to reduce errors

and save costs

Reduced to just 4 wires

Fastest response time of 5 ms

Also

Simple

Easy

type

Four times longer*

cutting oil resistance

Y-Joint

connector

with 4 wires

* Omron survey as of March 2017

The Easy type inherits the robust but slim housing and

basic safety features of the Advanced type. Simple

ON/OFF detection reduces errors, preventing

productivity from dropping.
