F3SG-RA

Spatter Protection Cover (2 covers per set, one for emitter and one for receiver)

Spatter Protection Covers include mounting brackets.

For Safety Light Curtain models of the protective height of 2,000 mm or longer, use two Spatter Protection Covers of different lengths.

Note: 1. The operating range of the Safety Light Curtain attached with the product is 10% shorter than the rating.

2. The product extends over the DIP Switch cover of the Safety Light Curtain. Be sure to use the product only after all required settings are

made to the DIP Switch.

Test Rod

Appearance

Safety Light Curtain Model

Model

Finger protection

Hand and arm protection

F3SG-4RA0160-14

F3SG-4RA0190-30

F39-HGA0200

F3SG-4RA0240-14

F3SG-4RA0270-30

F39-HGA0280

F3SG-4RA0320-14

F3SG-4RA0350-30

F39-HGA0360

F3SG-4RA0400-14

F3SG-4RA0430-30

F39-HGA0440

F3SG-4RA0480-14

F3SG-4RA0510-30

F39-HGA0520

F3SG-4RA0560-14

F3SG-4RA0590-30

F39-HGA0600

F3SG-4RA0640-14

F3SG-4RA0670-30

F39-HGA0680

F3SG-4RA0720-14

F3SG-4RA0750-30

F39-HGA0760

F3SG-4RA0800-14

F3SG-4RA0830-30

F39-HGA0840

F3SG-4RA0880-14

F3SG-4RA0910-30

F39-HGA0920

F3SG-4RA0960-14

F3SG-4RA0990-30

F39-HGA1000

F3SG-4RA1040-14

F3SG-4RA1070-30

F39-HGA1080

F3SG-4RA1120-14

F3SG-4RA1150-30

F39-HGA1160

F3SG-4RA1200-14

F3SG-4RA1230-30

F39-HGA1240

F3SG-4RA1280-14

F3SG-4RA1310-30

F39-HGA1320

F3SG-4RA1360-14

F3SG-4RA1390-30

F39-HGA1400

F3SG-4RA1440-14

F3SG-4RA1470-30

F39-HGA1480

F3SG-4RA1520-14

F3SG-4RA1550-30

F39-HGA1560

F3SG-4RA1600-14

F3SG-4RA1630-30

F39-HGA1640

F3SG-4RA1680-14

F3SG-4RA1710-30

F39-HGA1720

F3SG-4RA1760-14

F3SG-4RA1790-30

F39-HGA1800

F3SG-4RA1840-14

F3SG-4RA1870-30

F39-HGA1880

F3SG-4RA1920-14

F3SG-4RA1950-30

F39-HGA1960

F3SG-4RA2000-14

F3SG-4RA2030-30

F39-HGA1480

F39-HGA0550

F3SG-4RA2080-14

F3SG-4RA2110-30

F39-HGA1560

F39-HGA0550

−

F3SG-4RA2190-30

F39-HGA1640

F39-HGA0550

−

F3SG-4RA2270-30

F39-HGA1720

F39-HGA0550

−

F3SG-4RA2350-30

F39-HGA1800

F39-HGA0550

−

F3SG-4RA2430-30

F39-HGA1880

F39-HGA0550

−

F3SG-4RA2510-30

F39-HGA1960

F39-HGA0550

Diameter

Model

14 mm dia.

F39-TRD14

30 mm dia.

F39-TRD30
