F3SG-R 데이터시트(PDF) 31 Page - Omron Electronics LLC |
|
|
|||||||||||||||||||||||||||||
F3SG-R 데이터시트(HTML) 31 Page - Omron Electronics LLC |
|
31 / 164 page ![]() F3SG-RA 31 Input/Output Circuit Entire Circuit Diagram The entire circuit diagram of the F3SG-RA is shown below. The numbers in the circles indicate the connector's pin numbers. PNP Output 2 1 5 8 7 6 +24 VDC 1 2 4 Brown Black TEST White Not used Blue Brown White OSSD 2 Pink MUTE B Gray MUTE A Black OSSD 1 Red AUX Blue 3 Reset input circuit 4 Muting input circuit B 3 Muting input circuit A Yellow RESET 0 VDC 5 Yellow Not used Load Indicator Emitter Main Circuit Test Input Circuit Receiver Main Circuit 2 Receiver Main Circuit 1 Indicator Load Load |
|
