ntenance

Protective height

Specifications

Detection capability

14-mm dia.

160 to 2,080 mm

(15 to 207 beams)

30-mm dia.

190 to 2,510 mm

(8 to 124 beams)

See

p.16 for details.

See

p.44 for details.

See

p.73 for details.

14-mm dia./30-mm dia.

Accessory

Sold separately

・Standard fixed bracket

・Standard adjustable bracket

・Top/bottom adjustable bracket

(for user-made mounting part)

Connector

Beam gap

10 mm/20 mm

Operating range

0.3 to 10 m/

0.3 to 20 m

Brackets

Cable

Accessories (sold separately)

Sold separately

Connector

Detection capability

25-mm dia.

Beam gap

20 mm

Operating range

0.2 to 7 m

www.ia.omron.com/

25-mm dia.

185 to 1,105 mm

(8 to 54 beams)

14-mm dia.

240 to 1,920 mm

(23 to 191 beams)

25-mm dia.

240 to 1,920 mm

(12 to 96 beams)

14-mm dia.

160 to 2,080 mm

(15 to 207 beams)

30-mm dia.

190 to 2,510 mm

(8 to 124 beams)

Single/double-ended connector cable

Cascading cable

Reduced wiring connector

Laser pointer

Spatter protection cover

Lamp

Bluetoothcommunication unit

SD Manager2

Single/double-ended connector cable

Cascading cable

Reduced wiring connector

Laser pointer

Lamp

Bluetooth communication unit

SD Manager2

Single/double-ended connector cable

Reduced wiring connector

Laser pointer

Spatter protection cover

Detection capability

25-mm dia.

Beam gap

20 mm

Operating range

0.2 to 7 m

25-mm dia.

185 to 2,065 mm

(8 to 102 beams)

Detection capability

14-mm dia. -

Beam gap

9 mm -

Operating range

0.2 to 9 m

14-mm dia.

245 to 1,271 mm

(26 to 140 beams)

Detection capability

14-mm dia./25-mm dia.

Beam gap

10 mm/20 mm

Operating range

0.3 to 10 m/

0.3 to 17 m

Detection capability

14-mm dia./30-mm dia.

Accessory

Sold separately

・Standard fixed Bracket

・Standard adjustable bracket

・Top/bottom adjustable bracket

(for user-made mounting part)

Beam gap

10 mm/20 mm

Operating range

0.3 to 10 m/

0.3 to 20 m

* ENVIRONMENT RESISTANT type

Protective height: 225 to 1,985 mm Operating range: 0.2 to 6 m

* When the minimum object resolution is 14 mm

and the beam gap is 9 mm.

Refer to the F3SJ Series Catalog (Cat.

No. F074) or visit the Omron website

for details of the F3SJ Series.

F3SJ

andard fixed brac

See

p.4

See

p.1

See

p.7

・Free-Location

Bracket

(Intermediate Bracket)

・Top/bottom

Bracket (3types)

* The F3SG-RA-

□TS has different specifications.

See the following pages:F3SG-4RA-01TS: p.

93 F3SG-RA-02TS: p. 120

| 15
