78 / 168 page  2-40 DSP56362 Advance Information MOTOROLA Specifications External Memory Expansion Port (Port A) Figure 2-17 DRAM Out-of-Page Read Access Notes: 1. The number of wait states for out-of-page access is specified in the DCR. 2. The refresh period is specified in the DCR. 3. RD deassertion will always occur after CAS deassertion; therefore, the restricted timing is tOFF and not tGZ. 4. Either tRCH or tRRH must be satisfied for read cycles. Table 2-16 DRAM Out-of-Page and Refresh Timings, Fifteen Wait States 100 and 120MHz1, 2 (Continued) No. Characteristics3 Symbol Expression 100 MHz 120 MHz Unit Min Max Min Max RAS CAS A0–A17 WR RD D0–D23 Data Row Address Column Address In 157 163 165 162 162 169 170 171 168 167 164 166 173 174 175 172 177 176 191 160 168 159 193 161 192 158 179 AA0476 Freescale Semiconductor, Inc. For More Information On This Product, Go to: www.freescale.com |
|
